Single Epoxy
H907-500, magnetic adhesive, electromagnetic shielding adhesive, single component epoxy adhesive
CHARATERISTICS
The non-solvent H907-500 is a one-component epoxy adhesive, with low linear expansibility, good high temperature resistance, excellent shock and vibration resistance, high binding strength and hardness when cured
Appearance(uncured) | Black viscous fluid |
Specific Gravity(25°C) | 1.6-1.8 |
Viscosity(25°C) | 10000-30000 cps |
Shelf life | 1 months(25 oC) or 2 months(5 oC) |
Package | 200g, 500g, 1 kg, 5 kg |
TYPICAL APPLICATION
Bonding of magenetic conduction components, eg. high-performance magnetic components, electromagnetic clutch, controller, magnetic steel, ferrite, transformer core, inductor.
High bonding force, magenetic and electronical performance regarding to the bonding among metal, ceramics and glass substrates. The cured ones shown quite high hardness, bonding force, aging resistance. High resitance to oil/humidity/heat/dust.
PERFORMANCE
Typical properties cured for 1-2h @ 120°C (tunable)
Hardness | Shore D | 80-90 (tunable) |
Water absorption | 24 h | <0.3 % |
Compression strength | kg/mm2 | 50-60 |
Shear strength (steel/steel) | kg/mm2 | >=14 |
Tensile strength (iron/iron) | kg/mm2 | 10-15 |
Permittivity (1KHz) | / | 3.5 |
Note: The material specification tests include selected QC test parameters considered appropriate to specifications for customer use.
STORAGE
Seal perservation in low-temp, cool and dry place. Expired product only can be used after passing the performance test if needed.
