Single Epoxy
H907-HF single component epoxy resin adhesive, magnetic core adhesive, transformer adhesive
CHARATERISTICS
The non-solvent, low-halogen (Cl<900PPM) H907-HF is a general hard type, one-component flame retardat epoxy adhesive, with low linear expansibility, good high temperature resistance, excellent shock and vibration resistance, high binding strength and hardness when cured.
Appearance(uncured) | Black, white or grey paste |
Specific Gravity(25°C) | 1.45-1.55 |
Viscosity(25°C) | 55000-75000 cps |
Shelf life | 2 months(25 oC) or 3 months(5 oC) |
Package | 1 kg, 5 kg |
TYPICAL APPLICATION
Recommend the bonding and fixation of electric motors, circuit components, inductance coil, iron or magnetic core of high/low frequency transformers.
Good bonding force and performance with the insulation application among metal, ceramics, glass, fibre and hard plastics.
PERFORMANCE
Typical properties cured for 1-1.5 h @ 120+/-5°C
Hardness | Shore D | 85-95 |
Volume resistance | Ω-cm | 4.7E14 |
Surface resistance | Ω-cm | 5.8E13 |
Heat resistance | oC | 130-150 |
Tensile strength | kg/mm2 | 4.3 |
Voltage resistance | kv/mm | 16-18 |
Bonding strength (iron-iron) | kg/cm2 | 160-180 |
Water absorption | 24 h | <1 % |
Note: The material specification tests include selected QC test parameters considered appropriate to specifications for customer use.
